Vacuum suction systems

Huge choice of suction systems with up to 5000 kg capacity for flat, curved and waved elements of glass and stone and panels.

  • Suction systems for flat glass with up to 50000 kg capacity, also for coated and steamed panes. For the most part variable to fit pane size.

  • Vacuum lifting devices for curved and wavy panes of up to 6000 kg for sale or hire.

  • These extremely long and thin panes require special suction systems. Heavydrive® offers these suction systems in a wide range of sizes and loading capacities.

  • Suction units with a bearing load of up to 7000 kg can be equipped with a counterweight system! Available for rent or purchase!

  • The units of the Heavydrive series VSG KS are characterised by their extremely flat suction cups with simultaneously high carrying capacity. The flat units are available with a load capacity of 450 to 2,000 kilos.This makes the units particularly suitable for transporting and assembling pane elements behind the façade scaffolding.

  • This systems are predominantly used for curved bannisters, curved aquarium panes in zoos, curved boundary panels in showrooms, zoos and arched bridges. The stability is provided by several bonded laminated sheets with a very flat deflection of > 4000 mm.

  • Heavydrive®'s special rubber compound keeps the suction pads soft and flexible at temperatures below zero, just like snow tyres. This way, they can be used at temperatures as low as -20°C.

  • Due to its construction and suction plate form this panel suction system can be employed for both wall and roof panels It can be adjusted to fit the individual panel forms and profiles. By the deployment of extension arms even very long panels can also be safely and stabily transported.

  • Coated and vapour coated panes etc. are delicate therefore we have special non rub off suction plates for all our vacuum lifting devices ready for residue free handling. Non-marking plates leave no traces on vapour coated or mirrored panes for instance.

  • Special plates for rough surfaces such as stone slabs, plastic panels, wooden panels, wood based boards and much more up to 6000 kg.

  • Heavydrive offers a range of vacuum suction systems. Here you can find especially such, who are able lift panes up to 1000 kg.

  • Heavydrive offers a range of vacuum suction systems. Here you can find especially such, who are able lift panes up to 2500 kg.

  • Heavydrive offers a range of vacuum suction systems. Here you can find especially such, who are able lift heavy panes up to 14000 kg.

  • Vacuum suction system for workshop assembly of glass panes for window makers, glass processors......

  • Here you will find useful accessories for your counterweight beam.

  • Rental & Sales worldwide      /      Delivery-service 12h Germany-wide & 24h Europe-wide     /     Rental & Sales worldwide      /      Delivery-service 12h Germany-wide & 24h Europe-wide     /    Rental & Sales worldwide      /      Delivery-service 12h Germany-wide & 24h Europe-wide

    Device finder

    Load capacity:
    Maximum net weight:
    Lifting height:
    Device must be narrow, maximum:

    Further specifications
    Sort by:

    VSG Konter up to 9,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 13480 kg

    for curved panes, concave and convex, from 450 mm inner and outer radius,

    Minimum pane size: 1500 x 800 mm

    max. pane dimension for wall glazing: 4500 x 2300 mm
    max. pane dimension for roof glazing: 3500 x 1300 mm

    Net Weight : 440 kg

    Secure transport of panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this system adaptable to various panel sizes until 3.2m.



    • Perfect glazing even behind scaffolding due to the small depth of only 160 mm!
    • Overall depth in mm 160 mm
    • Suction (LxW) in mm (Base frame) 1,300 x 780
    max. pane dimension for wall glazing: 4350 x 3170 mm
    max. pane dimension for roof glazing: 3350 x 2170 mm

    Net Weight : 143 kg

    Secure transport of stone slabs between façades and frames with its low depth of 16 cm. Stone slabs can be held almost completely vertically. Extension arms make this System adaptable to various panel sizes until 3.2m.

    Net Weight : 140 kg

    Secure transport of coated panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this System adaptable to various panel sizes until 3.2m.

    max. pane dimension for wall glazing: 4350 x 3170 mm
    max. pane dimension for roof glazing: 3350 x 2170 mm

    Net Weight : 140 kg

    Secure transport of panes between façades and frames with its low depth of 16 cm at sub-zero temperatures.
    Panes can be held almost completely vertically. Extension arms make this system Adaptable to various panel sizes until 3.2m.

    max. pane dimension for wall glazing: 4350 x 3170 mm
    max. pane dimension for roof glazing: 3550 x 2170 mm

    Net Weight : 140 kg

    Vacuum suction system for heavy panes and façade elements up to 8.000 kg

    • Overall depth in mm 550
    • Suction (LxW) in mm (Base frame) 8,123 x 1,900
    • Suction (LxW) in mm with extension arms 14,073 x 2,200 short arms / 20,073 x 2,200 long arms
    max. pane dimension for wall glazing: 22073 x 4200 mm
    max. pane dimension for roof glazing: 21073 x 3200 mm

    Net Weight : 2700 kg

    VSG Konter up to 8,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 11480 kg

    12 plates, suction length of 2800 mm. Supplied on a roll truck.

    max. pane dimension for wall glazing: 2300 x 2200 mm
    max. pane dimension for roof glazing: 1300 x 1200 mm

    Net Weight : 220 kg

    for curved panes, concave and convex, inner and outer radius from 450mm

    Pane dimensions min.: 1.200 x 1.000 mm

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 320 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,200 x 1,000

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 320 kg

    Minimum pane size: 810 x 700 mm

    max. pane dimension for wall glazing: 2300 x 2200 mm
    max. pane dimension for roof glazing: 1300 x 1200 mm

    Net Weight : 220 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius, 30 plates, manually rotatable, hydraulically tippable. with remote control, 400 kg weight, suction length: 1125 mm, incl. roll truck

    max. pane dimension for wall glazing: 4500 x 2300 mm
    max. pane dimension for roof glazing: 3500 x 1300 mm

    Net Weight : 400 kg

    Secure transport of panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this system adaptable to various panel sizes.



    • Perfectly suited to glazing behind scaffolding
    • Suction (LxW) in mm (Base frame) 1,300 x 780
    • Suction (LxW) in mm with extension arms 2,140 x 1,360
    max. pane dimension for wall glazing: 4140 x 3360 mm
    max. pane dimension for roof glazing: 3140 x 2360 mm

    Net Weight : 134 kg

    VSG 750 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 3000 x B 6000 mm.

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 410 kg

    Extension arms 360° freely attachable

    Minimum pane size: 810 x 700 mm

    max. pane dimension for wall glazing: 4200 x 3300 mm
    max. pane dimension for roof glazing: 3200 x 2300 mm

    Net Weight : 127 kg

    VSG Konter up to 7,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 8400 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg

    Vacuum suction system for heavy panes and/or façade elements up to 7000 kg load capacity.

    Minimum pane size: 6,123 x 1,900 mm

    max. pane dimension for wall glazing: 21073 x 4200 mm
    max. pane dimension for roof glazing: 20073 x 3200 mm

    Net Weight : 2500 kg
    • for mounting lightweight panes weighing up to 70 kg
    Net Weight : 17 kg

    Suctionable in inner and outer radius

    Minimum pane size: 10,000 x 1,800 mm

    max. pane dimension for wall glazing: 13500 x 3300 mm
    max. pane dimension for roof glazing: 11500 x 2300 mm

    Net Weight : 3900 kg
    Net Weight : 87 kg

    Vacuum suction system for heavy panes and façade elements up to 6000 kg

    • Overall depth in mm 550
    • Suction (LxW) in mm (Base frame) 6,123 x 1,900
    • Suction (LxW) in mm with extension arms 12,073 x 2,200 short arms / 18,073 x 2,200 long arms
    max. pane dimension for wall glazing: 20073 x 4200 mm
    max. pane dimension for roof glazing: 19073 x 3200 mm

    Net Weight : 2500 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 160 plates, hydraulically swivelable, with remote control, 3900 kg weight, max. suction length: 6000 mm + 2x 3000 mm extension arms, incl. roll truck

    max. pane dimension for wall glazing: 7500 x 3300 mm
    max. pane dimension for roof glazing: 6500 x 2300 mm

    Net Weight : 3900 kg

    VSG Konter up to 6,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 7400 kg

    Vacuum suction system for heavy stone slabs and façade elements up to 6000 kg

    Minimum pane size: 6,123 x 1,900 mm

    max. pane dimension for wall glazing: 14073 x 4200 mm
    max. pane dimension for roof glazing: 13073 x 3200 mm

    Net Weight : 1800 kg

    Vacuum suction system for heavy panes and façade elements up to 6000 kg which are coated.

    max. pane dimension for wall glazing: 19073 x 4200 mm
    max. pane dimension for roof glazing: 19073 x 3200 mm

    Net Weight : 1800 kg

    Vacuum suction system for assembly at sub-zero temperatures of heavy glas panes and façade elements up to 6000 kg

    max. pane dimension for wall glazing: 20073 x 4200 mm
    max. pane dimension for roof glazing: 19073 x 3200 mm

    Net Weight : 1800 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg
    • With 4 arms that can be added or removed instantly.
    • Suction (L x W) in mm (base frame) 810 x 700
    • Suction (LxW) in mm with extension arms 2,200 x 1,300
    max. pane dimension for wall glazing: 4200 x 3300 mm
    max. pane dimension for roof glazing: 3200 x 2300 mm

    Net Weight : 65 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius, 24 plates, manually rotatable, hydraulically tippable, with remote control, 250 kg weight, suction length: 1125 mm, incl. roll truck

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 276 kg
    • Ultra-thin: Only 160 mm wide, this device will always fit between the frame and the façade!
    • Suction (LxW) in mm (Base frame) 1,300 x 780
    • Suction (LxW) in mm with extension arms 2,400 x 1,300
    max. pane dimension for wall glazing: 4400 x 3300 mm
    max. pane dimension for roof glazing: 3400 x 2300 mm

    Net Weight : 125 kg

    Vacuum suction system for wall and roof panels up to 12 m.

    max. pane dimension for wall glazing: 12500 x 3000 mm
    max. pane dimension for roof glazing: 12500 x 2000 mm

    Net Weight : 200 kg

    Vacuum suction system for wall and roof panels up to 18 m.

    max. pane dimension for wall glazing: 18500 x 3000 mm
    max. pane dimension for roof glazing: 18500 x 2000 mm

    Net Weight : 280 kg

    Vacuum suction system for wall and roof panels up to 24 m.

    max. pane dimension for wall glazing: 24551 x 3000 mm
    max. pane dimension for roof glazing: 24551 x 2000 mm

    Net Weight : 280 kg

    Vacuum suction system for wall and roof panels up to 8 m.

    max. pane dimension for wall glazing: 8500 x 2000 mm
    max. pane dimension for roof glazing: 8500 x 2000 mm

    Net Weight : 260 kg

    Vacuum suction system for assembling glass fins up to 1000 kg and 12 m width.

    Net Weight : 350 kg
    • for safe trannsport and setting of panes up to 2,800mm suction length
    • robust and solid construction
    max. pane dimension for wall glazing: 4400 x 2800 mm
    max. pane dimension for roof glazing: 3400 x 1800 mm

    Net Weight : 70 kg

    The perfect solution for lifting and installing window elements weighing up to 600 kg.

    Minimum pane size: 810 x 700 mm

    max. pane dimension for wall glazing: 4400 x 2800 mm
    max. pane dimension for roof glazing: 3400 x 1800 mm

    Net Weight : 70 kg
    • suitable for long glass fins

    Minimum pane size: 2.000 x 300 mm

    max. pane dimension for wall glazing: 4000 x 2300 mm
    max. pane dimension for roof glazing: 3000 x 1300 mm

    Net Weight : 82 kg
    • suitable for extra-long glass fins
    max. pane dimension for wall glazing: 6000 x 2300 mm
    max. pane dimension for roof glazing: 5000 x 1300 mm

    Net Weight : 101 kg
    • suitable for extra-long glass fins
    max. pane dimension for wall glazing: 10000 x 2400 mm
    max. pane dimension for roof glazing: 9000 x 1400 mm

    Net Weight : 116 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 330
    • Pane dimensions (LxW) LA9 in mm 12,123 x 330
    • Pane dimensions (LxW) LA12 in mm 15,123 x 330
    • Pane dimensions (LxW) LA14 in mm  17,123 x 330
    max. pane dimension for wall glazing: 17123 x 330 mm
    max. pane dimension for roof glazing: 17123 x 330 mm

    Net Weight : 450 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,200 x 1,000

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 276 kg

    Suitable for long, narrow panes (glass fins/glass beams)

    Minimum pane size: 2,000 x 400 mm

    max. pane dimension for wall glazing: 10000 x 2400 mm
    max. pane dimension for roof glazing: 9000 x 1400 mm

    Net Weight : 116 kg
    • Very variable due to 4 attachable/detachable arms

      Minimum pane size: 817 x 707 mm

    Net Weight : 220 kg

    Suitable for long, narrow panes (glass fins/glass beams)

    Minimum pane size: 1350 x 350 mm

    max. pane dimension for wall glazing: 5300 x 3200 mm
    max. pane dimension for roof glazing: 3350 x 2100 mm

    Net Weight : 95 kg

    Suitable for long, narrow panes (glass fins/glass beams)

    Minimum pane size: 2000 x 1110 mm

    max. pane dimension for wall glazing: 7900 x 3200 mm
    max. pane dimension for roof glazing: 7000 x 2600 mm

    Net Weight : 105 kg

    For mounting longitudinally curved panes

    Minimum pane dimensions: 4000 x 1500 mm

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 410 kg

    Vacuum suction system for screen printing and stone slabs up to 540 kg.

    Net Weight : 220 kg

    Currently the BIGGEST SYSTEM on the market! Lifts, rotates and pivots panes up to 24 metres in length, 3.2 m wide and weighing up to 5,000 kg with the highest level of safety and precision!

    • Overall depth in mm 550
    • Suction (LxW) in mm (Base frame) 6,123 x 1,900
    • Suction (L x W) in mm with extension arms 12,073 x 2,200 short arms / 18,073 x 2,200 long arms
    max. pane dimension for wall glazing: 20073 x 4200 mm
    max. pane dimension for roof glazing: 19073 x 3200 mm

    Net Weight : 2500 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 134 plates, hydraulically swivelable, with remote control, 2800 kg weight, max. suction length: 6000 mm + 2x 3000 mm extension arms, incl. roll truck

    max. pane dimension for wall glazing: 19073 x 2200 mm
    max. pane dimension for roof glazing: 19073 x 2200 mm

    Net Weight : 2800 kg

    VSG Konter up to 5,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 6800 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg

    For curved panes, convex and concave, from 450 mm inner and outer radius, 24 plates, manually rotatable, hydraulically tippable, with remote control, 140 kg weight, suction length: 1125 mm, incl. roll truck

    max. pane dimension for wall glazing: 4500 x 2300 mm
    max. pane dimension for roof glazing: 3500 x 1300 mm

    Net Weight : 250 kg
    • very variable system with extension arms
    • Suction (LxW) in mm 1,188 x 829
    • Suction (LxW) in mm with extension arms 2,330 x 1,490 or (optional 4,050 x 700)
    max. pane dimension for wall glazing: 4118 x 3829 mm
    max. pane dimension for roof glazing: 3118 x 2829 mm

    Net Weight : 91 kg

    VSG Konter up to 500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane

    Net Weight : 1600 kg

    All-round suction system, variable thanks to attachable arms

    Minimum pane size: 810 x 700 mm

    max. pane dimension for wall glazing: 4400 x 2800 mm
    max. pane dimension for roof glazing: 3400 x 1800 mm

    Perfectly suited for huge panes up to 9 m long, up to 3.8 m wide and weighing up to 4,500 kg. Choose the highest safety standards with a 4-circuit system!

    • Overall depth in mm 550
    • Suction (LxW) in mm (Base frame) 4,300 x 1,810
    • Suction (LxW) in mm with extension arms 7,000 x 1,810

    max. pane dimension for wall glazing: 9000 x 3810 mm
    max. pane dimension for roof glazing: 8000 x 2810 mm

    Net Weight : 1350 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg

    VSG Konter up to 4,500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 6800 kg
    • Light system for window assembly up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high. The short hanger assists assembly in window openings.
    • Suction (L x W) in mm (base frame) 900 x 680
    • Suction (L x B) in mm with extension arms 2,100 x 680
    max. pane dimension for wall glazing: 3900 x 2500 mm
    max. pane dimension for roof glazing: 1900 x 1680 mm

    Net Weight : 45 kg
    • Perfectly suited to glazing behind scaffolding
    max. pane dimension for wall glazing: 4000 x 2300 mm
    max. pane dimension for roof glazing: 3000 x 1300 mm

    Net Weight : 40 kg
    • Perfectly suited to glazing behind scaffolding
    max. pane dimension for wall glazing: 5000 x 2300 mm
    max. pane dimension for roof glazing: 4000 x 1300 mm

    Net Weight : 55 kg
    • Safe transport of panes. Thanks to a super flat construction of 160 mm this is the best assistant for assembly behind scaffolding!
    • Suction (L x W) in mm 1,300 x 780 mm
    max. pane dimension for wall glazing: 3300 x 2780 mm
    max. pane dimension for roof glazing: 2300 x 1780 mm

    Net Weight : 116 kg
    • Perfectly suited to glazing behind scaffolding
    max. pane dimension for wall glazing: 8000 x 2300 mm
    max. pane dimension for roof glazing: 7000 x 1300 mm

    Net Weight : 80 kg

    VSG 450 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 2500 x B 6000 mm.

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 380 kg

    Light system for stone slab assembly up to 450 kg. Best suited to small sizes up to
    1m wide and 1,20m high. The short hanger assists assembly under protrusions.

    Net Weight : 45 kg

    Light system for assembly of coated panes up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high.
    The short hanger assists assembly under protrusions.

    max. pane dimension for wall glazing: 3900 x 2500 mm
    max. pane dimension for roof glazing: 1900 x 1680 mm

    Net Weight : 45 kg

    Light system for window assembly up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high.
    The short hanger assists assembly in window openings. Special cups for assemblys at sub-zero temperatures.

    max. pane dimension for wall glazing: 3900 x 2500 mm
    max. pane dimension for roof glazing: 1900 x 1680 mm

    Net Weight : 45 kg
    • for safe trannsport and setting of panes up to 2,800mm suction length
    • robust and solid construction
    max. pane dimension for wall glazing: 4400 x 2800 mm
    max. pane dimension for roof glazing: 3400 x 1800 mm

    Net Weight : 140 kg
    • Perfectly suited to glazing behind scaffolding
    max. pane dimension for wall glazing: 5000 x 2300 mm
    max. pane dimension for roof glazing: 4000 x 1300 mm

    Net Weight : 55 kg

    Vacuum suction system for screen-printed panels and stone slabs .Slabs are held in an almost vertical position. The suction length is 2800 mm

    Net Weight : 220 kg

    For mark-free installation of coated panes

    Minimum pane size: 1363 x 1290 mm

    max. pane dimension for wall glazing: 4998 x 2890 mm
    max. pane dimension for roof glazing: 3998 x 2290 mm

    Net Weight : 206 kg
    • from 450 mm on up can be suctioned at the inner or outer radius
    • Even wavy panes are not a problem
    • Min. Suction (L x W) in mm (base frame) 1,290 x 254
    • Max. Suction (L x W) in mm (base frame) 1,770 x 254
    max. pane dimension for wall glazing: 2290 x 1890 mm
    max. pane dimension for roof glazing: 2290 x 1890 mm

    Net Weight : 38 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) 1,290 x 254

    max. pane dimension for wall glazing: 2290 x 1860 mm
    max. pane dimension for roof glazing: 2290 x 1860 mm

    Net Weight : 38 kg

    Vacuum suction system for heavy panes and façade elements up to 4000 kg

    Minimum pane size: 6123 x 1900 mm

    max. pane dimension for wall glazing: 14100 x 3600 mm
    max. pane dimension for roof glazing: 13100 x 2600 mm

    Net Weight : 1800 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 108 plates, hydraulically swivelable, with remote control, 2500 kg weight, max. suction length: 4000 mm + 2x 400 mm extension arms, incl. roll truc

    max. pane dimension for wall glazing: 9500 x 3300 mm
    max. pane dimension for roof glazing: 8500 x 2330 mm

    Net Weight : 2500 kg

    VSG Konter up to 4,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 6300 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg

    For curved panes, concave and convex, from 450mm inner and outer radius, 16 plates, manually rotatable, hydraulically tippable, with remote control, 200 kg weight, suction length: 1125 mm, incl. roll truck

    max. pane dimension for wall glazing: 3200 x 2600 mm
    max. pane dimension for roof glazing: 3200 x 2600 mm

    Net Weight : 220 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,200 x 1,000

    max. pane dimension for wall glazing: 3200 x 2600 mm
    max. pane dimension for roof glazing: 3200 x 2600 mm

    Net Weight : 220 kg

    Vacuum suction system for heavy panes and façade elements up to 3.500 kg

    max. pane dimension for wall glazing: 11700 x 3970 mm
    max. pane dimension for roof glazing: 9673 x 2970 mm

    Net Weight : 1100 kg

    Vacuum suction system for heavy panes and façade elements up to 3500 kg

    • Overall depth in mm 420 mm
    • Suction (LxW) in mm min. (base frame) 2,250 x 1,500
    • Suction (LxW) in mm max. with extension arms 4,090 x 2,000 short arms / 5,890 x 2,000 long arms
    max. pane dimension for wall glazing: 7890 x 4000 mm
    max. pane dimension for roof glazing: 6890 x 3000 mm

    Net Weight : 680 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,123 x 550
    • Pane dimensions (LxW) LA12 in mm 15,123 x 550
    • Pane dimensions (LxW) LA14 in mm 17,123 x 550
    max. pane dimension for wall glazing: 17123 x 550 mm
    max. pane dimension for roof glazing: 17123 x 550 mm

    Net Weight : 490 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
    • Pane dimensions (LxW) LA9 in mm 12,270 x 550
    • Pane dimensions (LxW) LA12 in mm 15,270 x 550
    • Pane dimensions (LxW) LA14 in mm 19,270 x 550
    max. pane dimension for wall glazing: 19270 x 550 mm
    max. pane dimension for roof glazing: 19270 x 550 mm

    Net Weight : 1300 kg

    VSG Konter up to 3,500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 4600 kg

    VSG Konter up to 3,500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 5700 kg

    Functions made possible by this suction system:

    • pick-up of glass panes/metal sheets from a table
    • swivel continuously upwards and downwards through 180 degrees
    • and return to trestles

    For slab dimensions: 4500 x 1500 mm

    • The light aluminium frame with 4 plates easily lifts wall panes of up to 3m x 3m and 320 kg
    • Suction (LxW) in mm 769 x 642
    • Suction (LxW) in mm with extension arms 1,643 x 1,152
    max. pane dimension for wall glazing: 3642 x 2769 mm
    max. pane dimension for roof glazing: 2642 x 1769 mm

    Net Weight : 58 kg
    • The all-rounder for wall and roof panes measuring
    • Suction (LxW) in mm 1,290 x 305
    max. pane dimension for wall glazing: 3290 x 1305 mm
    max. pane dimension for roof glazing: 2290 x 1305 mm

    Net Weight : 34 kg

    Vacuum suction system for heavy panes and façade elements up to 3000 kg

    • Overall depth in mm 420 mm
    • Suction (LxW) in mm min. (base frame) 2,250 x 1,500 mm
    • Suction (LxW) in mm max. with extension arms 4,090 x 2,000 mm short arms / 5,890 x 2,000 long arms
    max. pane dimension for wall glazing: 7890 x 4000 mm
    max. pane dimension for roof glazing: 6890 x 3000 mm

    Net Weight : 680 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 80 plates, hydraulically swivelable, with remote control, 600 kg weight, max. suction length: 3000 mm, incl. roll truck

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 2300 kg

    VSG Konter up to 3,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 4100 kg

    Vacuum suction system for assembling glass fins up to 3000 kg and 16 m width.



    Net Weight : 700 kg

    Suitable for heavy lifting and transport tasks, ideal for industrial applications.

    max. pane dimension for wall glazing: 12000 x 3970 mm
    max. pane dimension for roof glazing: 12000 x 2970 mm

    • Option to fit with a short suspension arm (570 mm) for assembling skylights in conservatories, for example
    • Suction (LxW) in mm 900 x 680
    max. pane dimension for wall glazing: 2900 x 1680 mm
    max. pane dimension for roof glazing: 1900 x 1680 mm

    Net Weight : 34 kg
    • for secure lifting of partially split window elements
    • minimum pane size: 700 x 700 mm
    • max. pane size for wall glazing: 2000 x 2000 mm
    max. pane dimension for wall glazing: 2000 x 2000 mm
    Net Weight : 35 kg

    Lightweight vacuum suction system for stone, fiber composite and screen printing plates up to 300 kg.

    Minimum size of the lifting goods (suction area): 1800 x 1200 mm

    max. pane dimension for wall glazing: 4200 x 3300 mm
    max. pane dimension for roof glazing: 3200 x 2300 mm

    Net Weight : 65 kg

    The power package with a capacity of 2800 kg. The solid and rigid construction allows the pane to be set in any conceivable position by remote control.

    Minimum pane size: 2100 x 1620 mm

    max. pane dimension for wall glazing: 7900 x 3620 mm
    max. pane dimension for roof glazing: 6900 x 2620 mm

    Net Weight : 620 kg

    4 plates, 26 kg weight, suction length: 1290 mm, incl. wooden crate

    max. pane dimension for wall glazing: 2800 x 1800 mm
    max. pane dimension for roof glazing: 1800 x 800 mm

    Net Weight : 34 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) 1,290 x 254

    max. pane dimension for wall glazing: 2290 x 1860 mm
    max. pane dimension for roof glazing: 2290 x 1860 mm

    Net Weight : 34 kg

    Lightweight vacuum suction system for screen printing and stone slabs up to 270 kg.

    Net Weight : 58 kg

    Lightweight vacuum suction system for screen printing and stone slabs up to 270 kg.

    Net Weight : 34 kg

    This is the power house of all the heavy load suction systems with a capacity of 2,500 kg. Its massive and rigid structure powered by remote control enables panes to be fitted in any space imaginable. Due to its adjustable suction pads the system can be adapted to fit any part up to 8 m in length and 4 m in width.

    • Overall depth in mm 380
    • Suction (L x W) in mm (base frame) 3,400 x 2,650
    • Suction (LxW) in mm with extension arms 6,700 x 1,650
    max. pane dimension for wall glazing: 8700 x 3650 mm
    max. pane dimension for roof glazing: 7700 x 2650 mm

    Net Weight : 600 kg

    Vacuum suction system for assembling glass fins up to 2500 kg and 16 m width.

    Net Weight : 700 kg

    This is the power house of all the heavy load suction systems with a capacity of 2,500 kg. Its massive and rigid structure powered by remote control enables Stone slabs to be fitted in any space imaginable. Due to its adjustable suction pads the system can be adapted to fit any part up to 8 m in length and 4 m in width.

    max. pane dimension for wall glazing: 6460 x 3280 mm
    max. pane dimension for roof glazing: 5460 x 2280 mm

    Net Weight : 700 kg

    This is the power house of all the heavy load suction systems for coated panes with a capacity of 2,500 kg. Its massive and rigid structure powered by remote control enables panes to be fitted in any space imaginable. Due to its adjustable suction pads the System can be adapted to fit any part up to 8 m in length and 4 m in width.

    max. pane dimension for wall glazing: 8700 x 3650 mm
    max. pane dimension for roof glazing: 7700 x 2650 mm

    Net Weight : 700 kg

    This is the power house of all the heavy load suction systems with a capacity of 2,500 kg. Its massive and rigid structure powered by remote control enables panes to be fitted in any space imaginable. Due to its adjustable suction pads the system can be adapted to fit any part up to 8 m in length and 4 m in width.

    max. pane dimension for wall glazing: 8700 x 3650 mm
    max. pane dimension for roof glazing: 7700 x 2650 mm

    Net Weight : 700 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 330
    • Pane dimensions (LxW) LA9 in mm 12,123 x 330
    • Pane dimensions (LxW) LA12 in mm 15,123 x 330
    • Pane dimensions (LxW) LA14 in mm 17,123 x 330
    max. pane dimension for wall glazing: 17123 x 330 mm
    max. pane dimension for roof glazing: 17123 x 330 mm

    Net Weight : 450 kg

    VSG 2200 KR vacuum suction unit for heavy curved panes.

    Minimum pane size: 50000 x 800 mm

    max. pane dimension for wall glazing: 8000 x 4100 mm
    max. pane dimension for roof glazing: 6000 x 3100 mm

    Net Weight : 1000 kg

    This medium-sized heavy load suction system has a 2.000kg capacity and can be used to securely install massive panes, for example aquarium panes of up to 5 m in length with its remote-controlled, fully hydraulic rotation and swivel unit.



    • Overall depth in mm 380
    • Suction (L x W) in mm (base frame) 2,150 x 1,200
    • Suction (LxW) in mm with extension arms 3,660 x 1,530
    max. pane dimension for wall glazing: 5660 x 3530 mm
    max. pane dimension for roof glazing: 4660 x 2530 mm

    Net Weight : 305 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 60 plates, hydraulically swivelable, with remote control, 500 kg weight, max. suction length: 3000 mm, incl. roll truck

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 720 kg

    VSG Konter up to 2,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 3100 kg

    This medium-sized heavy load suction system has a 2,000 kg capacity and can be used to securely install massive panes, for example aquarium panes of up to 8 m in length with its remote-controlled, fully hydraulic rotation and swivel unit.



    • Overall depth in mm 220
    • Suction (L x W) in mm (base frame) 2,070 x 1,576
    • Suction (LxW) in mm with extension arms 3,630 x 1,576
    max. pane dimension for wall glazing: 5630 x 3576 mm
    max. pane dimension for roof glazing: 4630 x 2576 mm

    Net Weight : 515 kg

    This medium-sized heavy load suction system has a 2.000kg capacity and can be used to securely install massive panes, for example aquarium panes of up to 5 m in length with its remote-controlled, fully hydraulic rotation and swivel unit.

    • Overall depth in mm 380
    • Suction (L x W) in mm (base frame) 2,150 x 1,200
    • Suction (LxW) in mm with extension arms 5,280 x 2,220
    max. pane dimension for wall glazing: 7280 x 4220 mm
    max. pane dimension for roof glazing: 6280 x 3220 mm

    Net Weight : 305 kg

    This medium-sized heavy load suction system has a 2.000kg capacity and can be used to securely install massive panes, for example aquarium panes of up to 6 m in length with its remote-controlled, fully hydraulic rotation and swivel unit.



    • Overall depth in mm 380
    • Suction (LxW) in mm (Base frame) 1,750 x 1,300
    • Suction (LxW) in mm with extension arms 4,000 x 1,300
    max. pane dimension for wall glazing: 6000 x 3300 mm
    max. pane dimension for roof glazing: 4000 x 1300 mm

    Net Weight : 400 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 330
    • Pane dimensions (LxW) LA9 in mm 12,123 x 330
    • Pane dimensions (LxW) LA12 in mm 15,123 x 330
    • Pane dimensions (LxW) LA14 in mm 17,123 x 330
    max. pane dimension for wall glazing: 17123 x 330 mm
    max. pane dimension for roof glazing: 17123 x 330 mm

    Net Weight : 450 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 2,250 x 1,500

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 720 kg
    • ideally suited for storey glazing
    • adjustable in height and depth, each can be adjusted to the projection (mas. 1.5 m)

    Suitable for heavy lifting and transport tasks, ideal for industrial applications.

    max. pane dimension for wall glazing: 12000 x 3970 mm
    max. pane dimension for roof glazing: 12000 x 2970 mm

    Vacuum suction systems for the assembly of glass swords  up to 2000 kg and 18 m span.

    Net Weight : 850 kg

    Lightweight vacuum suction system for screen-printed panels and stone slabs up to 200 kg.
    Minimum size of the load (suction area): 1800 x 1200 mm

    Net Weight : 260 kg

    For the safe transport of vacuum suction systems for wall and roof panels

    Net Weight : 20 kg

    Vacuum suction system for assembling glass fins up to 1800 kg and 12 m width.

    Net Weight : 350 kg

    Vacuum suction system for assembling glass fins up to 1800 kg and 12 m width.

    Net Weight : 350 kg

    For mounting longitudinally curved panes

    Minimum pane size: 4000 x 1500 mm

    max. pane dimension for wall glazing: 12673 x 4500 mm
    max. pane dimension for roof glazing: 11673 x 3500 mm

    Net Weight : 750 kg

    VSG Konter up to 16,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 20480 kg

    extremely flexible suction system

    Minimum pane size: 21500 x 1300 mm

    max. pane dimension for wall glazing: 7150 x 2800 mm
    max. pane dimension for roof glazing: 5150 x 1800 mm

    Net Weight : 280 kg

    Thanks to its manual rotation unit and fully hydraulic tilting unit this smallest among the heavy-duty suction system with 1500 kg capacity enables roof and wall mounting of elements up to 7 meters long.

    max. pane dimension for wall glazing: 9560 x 2800 mm
    max. pane dimension for roof glazing: 8560 x 1800 mm

    Net Weight : 280 kg

    This medium-sized heavy load suction system has a 1,500 kg capacity and can be used to securely install massive panes,

    max. pane dimension for wall glazing: 6460 x 2380 mm
    max. pane dimension for roof glazing: 5460 x 1380 mm

    Net Weight : 350 kg

    This medium-sized heavy load suction system has a 1,500 kg capacity and can be used to securely install massive panes, Very narrow version.



    • Overall depth in mm 220, Extra Narrow!
    • Suction (L x W) in mm (base frame) 2,070 x 1,070
    • Suction (LxW) in mm with extension arms 2,900 x 1,560
    max. pane dimension for wall glazing: 4900 x 3560 mm
    max. pane dimension for roof glazing: 3900 x 2560 mm

    Net Weight : 270 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius.

    Minimum pane size: variable up to 1.800 x 1.000 mm

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 640 kg

    Vacuum suction system for assembling glass fins up to 1500 kg and 12 m width.

    Net Weight : 350 kg

    This medium-sized heavy load suction system has a 1,500 kg capacity and can be used to securely install massive stone slabs. Very narrow version.

    max. pane dimension for wall glazing: 4900 x 3560 mm
    max. pane dimension for roof glazing: 3900 x 2560 mm

    Net Weight : 240 kg

    This medium-sized heavy load suction system for coated panes has a 1,500 kg capacity and can be used to securely install massive panes. Very narrow version.

    max. pane dimension for wall glazing: 4900 x 3560 mm
    max. pane dimension for roof glazing: 3900 x 2560 mm

    Net Weight : 240 kg

    This medium-sized heavy load suction system has a 1,500 kg capacity and can be used to securely install massive panes at sub-zero temperatures. Very narrow version.

    max. pane dimension for wall glazing: 4900 x 3560 mm
    max. pane dimension for roof glazing: 3900 x 2560 mm

    Net Weight : 240 kg

    Thanks to its manual rotation unit and fully hydraulic tilting unit this smallest among the heavy-duty suction system with 1.500 kg capacity enables roof and wall mounting of elements up to 6 meters long.

    • Overall depth in mm 380
    • Suction (L x W) in mm (base frame) 1,750 x 1,300
    • Suction (LxW) in mm with extension arms 4,000 x 1,300
    max. pane dimension for wall glazing: 6000 x 3300 mm
    max. pane dimension for roof glazing: 5000 x 2300 mm

    Net Weight : 305 kg
    • Ideal for setting very long glass fins
    • Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 330
    • Pane dimensions (LxW) LA9 in mm 12,123 x 330
    • Pane dimensions (LxW) LA12 in mm 15,123 x 330
    • Pane dimensions (LxW) LA14 in mm 17,123 x 330
    max. pane dimension for wall glazing: 17123 x 330 mm
    max. pane dimension for roof glazing: 17123 x 330 mm

    Net Weight : 450 kg

    VSG Konter up to 1,500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 2600 kg

    Vacuum suction system for heavy curved panes up to 1500 kg.

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 540 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,800 x 1,000

    max. pane dimension for wall glazing: 4800 x 2600 mm
    max. pane dimension for roof glazing: 4800 x 2600 mm

    Net Weight : 540 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 2,250 x 1,500

    max. pane dimension for wall glazing: 7550 x 3020 mm
    max. pane dimension for roof glazing: 7550 x 3020 mm

    Net Weight : 640 kg

    for holding and lifting prefabricated façade elements

    Net Weight : 500 kg

    extremely flexible suction system

    Minimum pane size: 1300 x 1300 mm

    max. pane dimension for wall glazing: 6300 x 2800 mm
    max. pane dimension for roof glazing: 4300 x 1800 mm

    Net Weight : 260 kg

    For mounting longitudinally curved panes

    Minimum pane size: 4000 x 1500 mm

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 760 kg

    for curved sheets, concave and convex suction

    Minimum sheet size: 610 x 600 mm

    max. pane dimension for wall glazing: 3000 x 2500 mm
    max. pane dimension for roof glazing: 2000 x 1500 mm

    Net Weight : 127 kg

    VSG Konter up to 14,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 18480 kg

    Light system for window mounting up to 135kg. Suitable for small pane sizes upt to 1m wide an 1,20m high. The short suspension supports assembly into the window frame.

    max. pane dimension for wall glazing: 2100 x 1700 mm
    max. pane dimension for roof glazing: 1100 x 700 mm

    Net Weight : 24 kg
    • Particularly suited for mounting thin and curved panes (e.g. windscreens)
    • Suction (L x W) in mm: 610 x 210
    max. pane dimension for wall glazing: 1210 x 2610 mm
    max. pane dimension for roof glazing: 1210 x 1610 mm

    Net Weight : 34 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius, 40 plates, manually rotatable, hydraullically tippable, with remote control, 480 kg weight, max. suction length: 3000 mm, incl. roll truck

    max. pane dimension for wall glazing: 4800 x 2600 mm
    max. pane dimension for roof glazing: 4800 x 2600 mm

    Net Weight : 480 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,800 x 1,000

    max. pane dimension for wall glazing: 4800 x 2600 mm
    max. pane dimension for roof glazing: 4800 x 2600 mm

    Net Weight : 480 kg

    Vacuum suction system for extremely heavy panes and façade elements up to 12.000 kg

    • Overall depth in mm 690
    • Suction (LxW) in mm (Base frame) 8,123 x 1,900
    • Suction (LxW) in mm with extension arms 14,073 x 2,200 short arms / 20,073 x 2,200 long arms
    max. pane dimension for wall glazing: 22073 x 4200 mm
    max. pane dimension for roof glazing: 21073 x 3200 mm

    Net Weight : 4100 kg

    VSG Konter up to 12,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 16480 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 48 plates, hydraulically swivelable, with remote control, 500 kg weight, max. suction length: 2000 mm + 2x 500 mm extension arms, incl. roll truck

    max. pane dimension for wall glazing: 5500 x 3330 mm
    max. pane dimension for roof glazing: 4500 x 2330 mm

    Net Weight : 500 kg

    By means of this extremely narrow system with a depth of only 22 cm very long and wide facade panes of up to 1200 kg can be lifted between walls and scaffolding without a hitch.

    max. pane dimension for wall glazing: 4000 x 3100 mm
    max. pane dimension for roof glazing: 3000 x 2100 mm

    Net Weight : 250 kg

    VSG 1200 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 3000 x B 6000 mm.

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 510 kg

     This medium-sized heavy load suction system has a 1.200 kg capacity and can be used to securely install massive pane.

    • Suction (L x W) in mm (base frame) 1,125 x 862
    • Suction (LxW) in mm with extension arms 2,800 x 862
    max. pane dimension for wall glazing: 4800 x 2862 mm
    max. pane dimension for roof glazing: 3800 x 1862 mm

    Net Weight : 240 kg

     This medium-sized heavy load suction system has a 1.200 kg capacity and can be used to securely install massive pane.

    • Suction (L x W) in mm (base frame) 1,125 x 862
    • Suction (LxW) in mm with extension arms 2,800 x 862
    max. pane dimension for wall glazing: 4800 x 2862 mm
    max. pane dimension for roof glazing: 3800 x 1862 mm

    Net Weight : 240 kg

    Suction system with 5 m span

    Minimum pane size: 1500 x 1100 mm

    max. pane dimension for wall glazing: 7000 x 3780 mm
    max. pane dimension for roof glazing: 6000 x 2780 mm

    Net Weight : 375 kg

    Suction system with 5 m span

    Net Weight : 290 kg

    For curved panes, concave and convex, from 450 mm inner und outer radius, 44 plates, hydraulically swivelable, with remote control, 500 kg weight, max. suction length: 3000 mm, incl. roll truck

    max. pane dimension for wall glazing: 4500 x 2300 mm
    max. pane dimension for roof glazing: 3500 x 1300 mm

    Net Weight : 500 kg

    This model is essentially similar to the model 1000 K. It differs only through its notably narrower design. Using the hydraulic tipping arm via radio remote control long and wide display windows up to 1000 kg can be fitted.



    • Overall depth in mm 220 mm
    • Suction (LxW) in mm (Base frame) 1,500 x 1,500 mm
    max. pane dimension for wall glazing: 4800 x 3600 mm
    max. pane dimension for roof glazing: 3800 x 2600 mm

    Net Weight : 148 kg

    Vacuum suction system for extremely heavy panes and façade elements up to 10,000 kg

    • Suction (LxW) in mm (Base frame) 8,123 x 1,900
    • Suction (LxW) in mm with extension arms 14,073 x 2,200 short arms / 20,073 x 2,200 long arms
    max. pane dimension for wall glazing: 22073 x 4200 mm
    max. pane dimension for roof glazing: 21073 x 3200 mm

    Net Weight : 3800 kg

    VSG Konter up to 10,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.

    Net Weight : 14480 kg

    Using the hydraulic tipping arm via remote control long and wide display windows up to 1000 kg can be fitted.

    • Suction (L x W) in mm (base frame) 1,125 x 862
    max. pane dimension for wall glazing: 3330 x 3192 mm
    max. pane dimension for roof glazing: 2330 x 2192 mm

    Net Weight : 180 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius, 24 plates, manually rotatable, hydraulically tippable, with remote control, 250 kg weight, suction length: 1125 mm, incl. roll truck

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 456 kg

    VSG 1000 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 3000 x B 6000 mm.

    max. pane dimension for wall glazing: 7500 x 3000 mm
    max. pane dimension for roof glazing: 6500 x 2000 mm

    Net Weight : 480 kg

    6 m long 2 strand chain hanger Counterweight with mobile steel plates With rechargeable batteries Remote control Adapter for any suction unit (depending on effort) The suitable suction unit can be selected from the VSG product group.

    Net Weight : 2100 kg

    Using the hydraulic tipping arm via remote control long and wide display windows up to 1000 kg can be fitted.

    • Suction (L x W) in mm (base frame) 1,363 x 1,290
    max. pane dimension for wall glazing: 4998 x 3290 mm
    max. pane dimension for roof glazing: 3998 x 2290 mm

    Net Weight : 206 kg

    Using the hydraulic tipping arm via remote control long and wide display windows up to 1000 kg can be fitted.

    • Suction (LxW) in mm with extension arms 4,900 x 1,740
    • Suction (L x W) in mm (base frame) 1,363 x 1,290
    max. pane dimension for wall glazing: 6900 x 3740 mm
    max. pane dimension for roof glazing: 5900 x 3740 mm

    Net Weight : 230 kg
    • Ideal for setting very long glass fins
    max. pane dimension for wall glazing: 17123 x 330 mm
    max. pane dimension for roof glazing: 17123 x 330 mm

    Net Weight : 450 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius, 40 plates, manually rotatable, hydraullically tippable, with remote control, 480 kg weight, max. suction length: 3000 mm, incl. roll truck

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 420 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,200 x 1,000

    max. pane dimension for wall glazing: 4200 x 2600 mm
    max. pane dimension for roof glazing: 4200 x 2600 mm

    Net Weight : 420 kg
    • Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms

    Min. Suction (L x W) in mm (base frame) variable up to 1,800 x 1,000

    max. pane dimension for wall glazing: 4800 x 2600 mm
    max. pane dimension for roof glazing: 4800 x 2600 mm

    Net Weight : 456 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius

    Minimum pane size: variable up to 3,500 x 1,000 mm

    max. pane dimension for wall glazing: 6000 x 3300 mm
    max. pane dimension for roof glazing: 4500 x 2800 mm

    Net Weight : 456 kg

    For curved panes, concave and convex, from 450 mm inner and outer radius

    Minimum pane size: variable up to 3,500 x 1,200 mm

    max. pane dimension for wall glazing: 6000 x 3300 mm
    max. pane dimension for roof glazing: 4500 x 2800 mm

    Net Weight : 780 kg

    for straight, curved, spherically curved glass panes; radius up to 450 mm convex or concave

    Minimum pane size: 3,500 x 1,200 mm

    max. pane dimension for wall glazing: 7000 x 3300 mm
    max. pane dimension for roof glazing: 4500 x 2800 mm

    Net Weight : 780 kg
    • Manufactured to IPPC standard
    • A forklift truck move below on one side
    • Can be lifted by hand with handles on the long side
    Net Weight : 8 kg

    Battery 12 V

    Net Weight : 8 kg

    Radio remote control for all VSG K systems.

    Net Weight : 0.2 kg

    Hydraulic unit for rotation function with cable remote control for VSG 1000 K- 1200K. Only suppliable with new orders.

     Vacuum suction systems for the hall asssembly of glass panes for window making, glass refining,,,,,

    VSG SZ Drop Drum for VSG 450 K- 900 K

    Net Weight : 5.2 kg

     Suctions plates for all VSG K-Anlagen

    Net Weight : 1.95 kg

    Enables installation 5 m below the overhang.

    Net Weight : 250 kg

    for all suction systems

    Net Weight : 200 kg

    Alternative for systems with normal arm, not in conjunction with a lowering cylinder

    for all suction systms

    Glass panes can then be easily parked on level ground.

    Net Weight : 500 kg

    suitable for All suction systems with swivel hooks, other materials

    This special cleaning solution increases the grip and extends the service life of the cup!

    All suction systems S1-5 / Q 1-5 / G 1-5

    All suction systems S1-5 / Q 1-5 / G 1-5

    suitable for VSGU 300/450/600 K

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5, other materials

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5, other materials

    All suction systems S1-5 / Q 1-5 / G 1-5, other materials

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5, other materials

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5, other materials

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5

    suitable for All suction systems S1-5 / Q 1-5 / G 1-5

    Suction plate protection covers for vacuum suction systems

    • Counterweight bracket for suction systems over 250 kg load capacity



    Net Weight : 500 kg

    Pneumatic lowering cylinder for VSG 300K-1500K

    Alternative for systems with normal arm, not in conjunction with a lowering cylinder

    for vacuum suction systems VSG 300-600 K
    Length: 220 mm

    Alternative for systems with normal arm, not in conjunction with a lowering cylinder

    for vacuum suction systems VSG 300-600 K
    Length: 620 mm

    All categories and products

    Videos with vacuum suction systems:

    Huge choice of suction systems with up to 5000 kg capacity for flat, curved and waved elements of glass and stone and panels.
