Glazing robots

The glass assembly device is a compact, mobile assembly aid that transports and installs panes with millimeter precision and a load capacity of up to 1,400 kilograms.

The low ceiling load of the glass robot enables easy glazing of heavy window elements in shell construction. The compact design supports the operator in every aspect of handling. All functions are fully automatic for safety reasons. The GMG devices have a 48-volt electric drive. The charged battery lasts three to four working days without recharging.

Glass installation devices and glass robots enable you to carry out your project safely and efficiently – Heavydrive offers these in many variations for rental and sale. Our range also includes used glass installation devices. Annual accident prevention inspections, spare parts, and a large selection of accessories round off our range.

Glass installation equipment, glazing robots, glass robots for rent or purchase

Rental & Sales worldwide / Delivery-service 12h Germany-wide & 24h Europe-wide / Rental & Sales worldwide / Delivery-service 12h Germany-wide & 24h Europe-wide / Rental & Sales worldwide / Delivery-service 12h Germany-wide & 24h Europe-wide

Device finder

Load capacity:

100 - 16000 kg

Maximum net weight:

Lifting height:

Device must be narrow, maximum:

› Further specifications

Remove filter

Sort by:

GMG 785 with a capacity of 785 kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions in square min.: 800 x 800 mm
pane dimension in line min.: 800 x 1.520 mm
pane vertikal dimensions max: 3.200 x 3.200 mm
pane horizontal dimensions max.: 1.700 x 1.700 mm

Net Weight : 1200 kg
Lift Height : 3.9 m

Product details

GMG 600 glass assembly equipment with a capacity of 600 kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions in square min.: 740 x 740 mm
pane dimension in line min.: 740 x 1.600 mm
pane vertikal dimensions max: 3.250 x 3.250 mm
pane horizontal dimensions max.: 2.250 x 2.250 mm

Net Weight : 865 kg
Lift Height : 3.6 m

Product details

GMG 575 glass assembly equipment with a capacity of 575 kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions in square min.: 730 x 730 mm
pane dimension in line min.: 730 x 1.300 mm
pane vertikal dimensions max: 4.540 x 4.540 mm
pane horizontal dimensions max.: 2.540 x 2.540 mm

Net Weight : 1025 kg
Lift Height : 3.6 m

Product details

GMG 400 glass handler with 460 kg load capacity

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions min.: 660 x 540 mm
pane vertikal dimensions max: 3.450 x 3.450 mm
pane horizontal dimensions max.: 2.450 x 2.450 mm

Net Weight : 375 kg
Lift Height : 2.56 m

Product details

GMG 375 glass assembly equipment with a capacity of 375 kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

Net Weight : 578 kg
Lift Height : 3 m

Product details

GMG 350 glass assembly equipment with a capacity of 350 kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions min.: 660 x 540 mm
pane vertikal dimensions max: 3.450 x 3.450 mm
pane horizontal dimensions max.: 2.450 x 2.450 mm

Net Weight : 350 kg
Lift Height : 2.5 m

Product details

GMG M 1400 - Power Glass Crawler with a capacity of 1400kg

the all-terrain glass handler

pane dimensions in square min.: 830 x 830 mm
pane dimension in line min.: 920 x 1.550 mm
pane vertikal dimensions max: 3.200 x 3.200 mm
pane horizontal dimensions max.: 1.700 x 1.700 mm

Net Weight : 2600 kg
Lift Height : 5.1 m

Product details

GMG 1000 Glass assembly device with a capacity of 1000kg

compact mobile assembly aid transports and places
glass panes with mm-precision
Precise fitting with fine stroke

pane dimensions in square min.: 830 x 830 mm
pane dimension in line min.: 920 x 1.550 mm
pane vertikal dimensions max: 3.200 x 3.200 mm
pane horizontal dimensions max.: 1.700 x 1.700 mm

Net Weight : 1340 kg
Lift Height : 4.1 m

Product details

GMG M 1000 - Power Glass Crawler with a capacity of 1000kg

the all-terrain glass handler

pane dimensions in square min.: 830 x 830 mm
pane dimension in line min.: 920 x 1.550 mm
pane vertikal dimensions max: 3.200 x 3.200 mm
pane horizontal dimensions max.: 1.700 x 1.700 mm

Net Weight : 2600 kg
Lift Height : 4.1 m

Product details
