Flexible articulated boom for a wide range of applications.
Tracked chassis for any surface
Suitable for indoor and outdoor use
Low dead weight
Net Weight
: 2370 kg
Lift Height
: 11.3 m
Selected additional services
:
Very small mini caterpillar crane with a capacity of 0.995 tonnes and a hook height of 5.5 m. It can be powered electrically by high voltage or by petrol or gas. Especially suitable for assembly in narrow and crammed locations.
Net Weight
: 1050 kg
Lift Height
: 5.5 m
Selected additional services
:
VSG Konter up to 9,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 13480 kg
Selected additional services
:
for curved panes, concave and convex, from 450 mm inner and outer radius,
Minimum pane size: 1500 x 800 mm
max. pane dimension for wall glazing: 4500 x 2300 mm
max. pane dimension for roof glazing: 3500 x 1300 mm
Net Weight
: 440 kg
Selected additional services
:
Secure transport of panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this system adaptable to various panel sizes until 3.2m.
Perfect glazing even behind scaffolding due to the small depth of only 160 mm!
Overall depth in mm 160 mm
Suction (LxW) in mm (Base frame) 1,300 x 780
max. pane dimension for wall glazing: 4350 x 3170 mm
max. pane dimension for roof glazing: 3350 x 2170 mm
Net Weight
: 143 kg
Selected additional services
:
900 kg capacity, 12 plates, 320 kg weight, 3 axis manipulator with cable remote control for MRK 126 - 158
Net Weight
: 320 kg
Selected additional services
:
Load capacity up to 7.5 m height = 800 kg
Lift by manual hand crank
Net Weight
: 415 kg
Lift Height
: 7.5 m
Selected additional services
:
Secure transport of stone slabs between façades and frames with its low depth of 16 cm. Stone slabs can be held almost completely vertically. Extension arms make this System adaptable to various panel sizes until 3.2m.
Net Weight
: 140 kg
Selected additional services
:
Secure transport of coated panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this System adaptable to various panel sizes until 3.2m.
max. pane dimension for wall glazing: 4350 x 3170 mm
max. pane dimension for roof glazing: 3350 x 2170 mm
Net Weight
: 140 kg
Selected additional services
:
Secure transport of panes between façades and frames with its low depth of 16 cm at sub-zero temperatures.
max. pane dimension for wall glazing: 4350 x 3170 mm
max. pane dimension for roof glazing: 3550 x 2170 mm
Net Weight
: 140 kg
Selected additional services
:
Selected additional services
:
long chassis
for many different applications
suitable for indoor and, with laid out floor plates, also for outdoor areas
Net Weight
: 644 kg
Lift Height
: 2.9 m
Selected additional services
:
Load capacity up to 3.3 m height = 900 kg
with battery-operated mast lift
Net Weight
: 237 kg
Lift Height
: 3.3 m
Selected additional services
:
Capacity 900 kg (up to 3.3 m)
with electrically powered mast hoist
Net Weight
: 237 kg
Lift Height
: 3.3 m
Selected additional services
:
for straight, curved, spherically curved glass panes; radius up to 450 mm convex or concave
Minimum pane size: 4,500 x 1,080 mm
max. pane dimension for wall glazing: 6340 x 3560 mm
max. pane dimension for roof glazing: 5540 x 2560 mm
Net Weight
: 450 kg
Selected additional services
:
Up to 900 kg load capacity
Selected additional services
:
From planning to assembly - Heavydrive is your partner when it comes to Helm running rails!
Selected additional services
:
High agility
Compact design enables work in confined spaces
Suitable for indoor and outdoor use
Designed for different tasks with different machine accessories
Net Weight
: 9750 kg
Lift Height
: 8 m
Selected additional services
:
Load capacity up to 4.7 m height = 850 kg
with battery-operated mast lift
Net Weight
: 237 kg
Lift Height
: 4.7 m
Selected additional services
:
Load capacity up to 4.7 m height = 850 kg
Lift by manual hand crank
Net Weight
: 237 kg
Lift Height
: 4.7 m
Selected additional services
:
Electrically via high-voltage current or with diesel for indoor and outdoor use
Pick & Carry function: 1,000 kg load capacity
Multifunctional display for optimum information visualisation
Net Weight
: 9460 kg
Lift Height
: 19.6 m
Selected additional services
:
Vacuum suction system for heavy panes and façade elements up to 8.000 kg
Overall depth in mm 550
Suction (LxW) in mm (Base frame) 8,123 x 1,900
Suction (LxW) in mm with extension arms 14,073 x 2,200 short arms / 20,073 x 2,200 long arms
max. pane dimension for wall glazing: 22073 x 4200 mm
max. pane dimension for roof glazing: 21073 x 3200 mm
Net Weight
: 2700 kg
Selected additional services
:
VSG Konter up to 8,000 kg capacity. Secure mounting of the pane under protrusions up to 6.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 11480 kg
Selected additional services
:
Double safety with full-stop wheels: Brakes in direction and position with only one lever pressure!
adjustable-length support up to 2 m
Min. pane dimensions in mm L 500 x H 500 Max. pane dimensions in mm L 6,000 x H 3,200
Net Weight
: 58 kg
Selected additional services
:
Selected additional services
:
12 plates, suction length of 2800 mm. Supplied on a roll truck.
max. pane dimension for wall glazing: 2300 x 2200 mm
max. pane dimension for roof glazing: 1300 x 1200 mm
Net Weight
: 220 kg
Selected additional services
:
for curved panes, concave and convex, inner and outer radius from 450mm
Pane dimensions min.: 1.200 x 1.000 mm
max. pane dimension for wall glazing: 4200 x 2600 mm
max. pane dimension for roof glazing: 4200 x 2600 mm
Net Weight
: 320 kg
Selected additional services
:
Minimum pane size: 810 x 700 mm
max. pane dimension for wall glazing: 2300 x 2200 mm
max. pane dimension for roof glazing: 1300 x 1200 mm
Net Weight
: 220 kg
Selected additional services
:
Load capacity up to 6.1 m height = 800 kg
with battery-operated mast lift
Net Weight
: 237 kg
Lift Height
: 6.1 m
Selected additional services
:
Capacity 800 kg (up to 6.1 m)
with electrically powered mast hoist
Net Weight
: 415 kg
Lift Height
: 6.1 m
Selected additional services
:
Load capacity up to 6.1 m height = 800 kg
Lift by manual hand crank
Net Weight
: 415 kg
Lift Height
: 6.1 m
Selected additional services
:
Load capacity up to 7.5 m height = 800 kg
with battery-operated mast lift
Net Weight
: 237 kg
Lift Height
: 7.5 m
Selected additional services
:
up to a load capacity of[nbsp800 kg
Selected additional services
:
compact mobile assembly aid transports and places
Precise fitting with fine stroke
pane dimensions in square min.: 800 x 800 mm
Net Weight
: 1473 kg
Lift Height
: 3.9 m
Selected additional services
:
An alternative to assembly crane MRK 195.0 but with a capacity of 7.5 tonnes and a heavy-load tip 5 m in length.
Net Weight
: 8100 kg
Lift Height
: 19.5 m
Selected additional services
:
For curved panes, concave and convex, from 450 mm inner and outer radius, 30 plates, manually rotatable, hydraulically tippable. with remote control, 400 kg weight, suction length: 1125 mm, incl. roll truck
max. pane dimension for wall glazing: 4500 x 2300 mm
max. pane dimension for roof glazing: 3500 x 1300 mm
Net Weight
: 400 kg
Selected additional services
:
Secure transport of panes between façades and frames with its low depth of 16 cm. Panes can be held almost completely vertically. Extension arms make this system adaptable to various panel sizes.
Perfectly suited to glazing behind scaffolding
Suction (LxW) in mm (Base frame) 1,300 x 780
Suction (LxW) in mm with extension arms 2,140 x 1,360
max. pane dimension for wall glazing: 4140 x 3360 mm
max. pane dimension for roof glazing: 3140 x 2360 mm
Net Weight
: 134 kg
Selected additional services
:
VSG 750 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 3000 x B 6000 mm.
max. pane dimension for wall glazing: 7500 x 3000 mm
max. pane dimension for roof glazing: 6500 x 2000 mm
Net Weight
: 410 kg
Selected additional services
:
Extension arms 360° freely attachable
Minimum pane size: 810 x 700 mm
max. pane dimension for wall glazing: 4200 x 3300 mm
max. pane dimension for roof glazing: 3200 x 2300 mm
Net Weight
: 127 kg
Selected additional services
:
narrow design with short chassis
for many different applications
suitable for indoor and, with laid out floor plates, also for outdoor areas
Net Weight
: 644 kg
Lift Height
: 2.9 m
Selected additional services
:
High agility
Compact design enables work in confined spaces
Suitable for indoor and outdoor use
Designed for different tasks with different machine accessories
Net Weight
: 8800 kg
Lift Height
: 9.5 m
Selected additional services
:
VSG Konter up to 7,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 8400 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
Pane dimensions (LxW) LA9 in mm 12,270 x 550
Pane dimensions (LxW) LA12 in mm 15,270 x 550
Pane dimensions (LxW) LA14 in mm 19,270 x 550
max. pane dimension for wall glazing: 19270 x 550 mm
max. pane dimension for roof glazing: 19270 x 550 mm
Net Weight
: 1300 kg
Selected additional services
:
Vacuum suction system for heavy panes and/or façade elements up to 7000 kg load capacity.
Minimum pane size: 6,123 x 1,900 mm
max. pane dimension for wall glazing: 21073 x 4200 mm
max. pane dimension for roof glazing: 20073 x 3200 mm
Net Weight
: 2500 kg
Selected additional services
:
low centre of gravity firm pane support and grasp, very flexible, shock absorbing rollers
Only 350 mm wide! Ideal for triple glazing!Can be operated behind scaffolding
Min. pane dimensions/mm L 2,000 x H 500
Max. pane dimensions/mm L 5,000 x H 2,500
Net Weight
: 52 kg
Selected additional services
:
Extra low centre of gravity ➔ Highly stable
Pane transport up to min. width of 500 mm and max. height of 3,200 mm
Min. pane dimensions in mm L 500 x H 500 Max. pane dimensions in mm L 4,000 x H 3,200
Net Weight
: 52 kg
Selected additional services
:
The total-stop shock-absorbing pneumatic tyres of the new HDL 700 A, with a bearing load of 700 kg, guarantee a safe grip in every position and direction. In addition to this, it can be extended up to 2 m.
for extensive window panels and façade elements
Adjustable length from 500 to 1700 mm
Min. pane dimensions in mm L 400 x H 1,500 Max. pane dimensions in mm L 4,000 x H 2,800
Net Weight
: 65 kg
Selected additional services
:
for mounting lightweight panes weighing up to 70 kg
Net Weight
: 17 kg
Selected additional services
:
Suctionable in inner and outer radius
Minimum pane size: 10,000 x 1,800 mm
max. pane dimension for wall glazing: 13500 x 3300 mm
max. pane dimension for roof glazing: 11500 x 2300 mm
Net Weight
: 3900 kg
Selected additional services
:
Net Weight
: 87 kg
Selected additional services
:
This powerful assembly crane has a capacity of 6.0 tonnes, is suitable for off-road use and movable under a load of 2.0 tonnes without supports.
Net Weight
: 15640 kg
Lift Height
: 16.7 m
Selected additional services
:
This assembly crane has a capacity of 6.0 tonnes and can be equipped with a heavy-load tip which extends it to a length of 22.7 m.
Net Weight
: 8070 kg
Lift Height
: 19.5 m
Selected additional services
:
Vacuum suction system for heavy panes and façade elements up to 6000 kg
Overall depth in mm 550
Suction (LxW) in mm (Base frame) 6,123 x 1,900
Suction (LxW) in mm with extension arms 12,073 x 2,200 short arms / 18,073 x 2,200 long arms
max. pane dimension for wall glazing: 20073 x 4200 mm
max. pane dimension for roof glazing: 19073 x 3200 mm
Net Weight
: 2500 kg
Selected additional services
:
For curved panes, concave and convex, from 450 mm inner und outer radius, 160 plates, hydraulically swivelable, with remote control, 3900 kg weight, max. suction length: 6000 mm + 2x 3000 mm extension arms, incl. roll truck
max. pane dimension for wall glazing: 7500 x 3300 mm
max. pane dimension for roof glazing: 6500 x 2300 mm
Net Weight
: 3900 kg
Selected additional services
:
VSG Konter up to 6,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 7400 kg
Selected additional services
:
Vacuum suction system for heavy stone slabs and façade elements up to 6000 kg
Minimum pane size: 6,123 x 1,900 mm
max. pane dimension for wall glazing: 14073 x 4200 mm
max. pane dimension for roof glazing: 13073 x 3200 mm
Net Weight
: 1800 kg
Selected additional services
:
Vacuum suction system for heavy panes and façade elements up to 6000 kg which are coated.
max. pane dimension for wall glazing: 20073 x 4200 mm
max. pane dimension for roof glazing: 19073 x 3200 mm
Net Weight
: 1800 kg
Selected additional services
:
Vacuum suction system for assembly at sub-zero temperatures of heavy glas panes and façade elements up to 6000 kg
max. pane dimension for wall glazing: 20073 x 4200 mm
max. pane dimension for roof glazing: 19073 x 3200 mm
Net Weight
: 1800 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
Pane dimensions (LxW) LA9 in mm 12,270 x 550
Pane dimensions (LxW) LA12 in mm 15,270 x 550
Pane dimensions (LxW) LA14 in mm 19,270 x 550
max. pane dimension for wall glazing: 19270 x 550 mm
max. pane dimension for roof glazing: 19270 x 550 mm
Net Weight
: 1300 kg
Selected additional services
:
This crane's compact design makes it the ideal choice for small construction sites and courtyards
Precise installation down to the last millimetre thanks to continuous control.
Intuitive and safe to use, can also be controlled by just one operator
Net Weight
: 15640 kg
Lift Height
: 16.7 m
Selected additional services
:
compact mobile assembly aid transports and places
Precise fitting with fine stroke
pane dimensions in square min.: 740 x 740 mm
Net Weight
: 1060 kg
Lift Height
: 3.6 m
Selected additional services
:
Large extension variety: 500 – 2000 mm
Shock-absorbing wheels incl. parking brake
Min. pane dimensions in mm L 500 x H 500 Max. pane dimensions in mm L 4,000 x H 3,200
Net Weight
: 52 kg
Selected additional services
:
The total-stop shock-absorbing pneumatic tyres of the new HDL 600 A, with a bearing load of 600 kg, guarantee a safe grip in every position and direction. In addition to this, it can be extended up to 2 m.
for extensive window panels and façade elements
Adjustable length from 500 to 1700 mm
Min. pane dimensions in mm L 400 x H 1,500 Max. pane dimensions in mm L 4,000 x H 2,800
Net Weight
: 65 kg
Selected additional services
:
600 kg capacity, battery-powered, raisable platform, for transport of liquids
Net Weight
: 354 kg
Selected additional services
:
600 kg capacity, battery-powered, standard design
Net Weight
: 354 kg
Selected additional services
:
600 kg capacity, battery-powered, platform swivels through 90 °, to pick up loads from the ground
Net Weight
: 354 kg
Selected additional services
:
With 4 arms that can be added or removed instantly.
Suction (L x W) in mm (base frame) 810 x 700
Suction (LxW) in mm with extension arms 2,200 x 1,300
max. pane dimension for wall glazing: 4200 x 3300 mm
max. pane dimension for roof glazing: 3200 x 2300 mm
Net Weight
: 65 kg
Selected additional services
:
Ultra-thin: Only 160 mm wide, this device will always fit between the frame and the façade!
Suction (LxW) in mm (Base frame) 1,300 x 780
Suction (LxW) in mm with extension arms 2,400 x 1,300
max. pane dimension for wall glazing: 4400 x 3300 mm
max. pane dimension for roof glazing: 3400 x 2300 mm
Net Weight
: 125 kg
Selected additional services
:
Vacuum suction system for wall and roof panels up to 12 m.
max. pane dimension for wall glazing: 12500 x 3000 mm
max. pane dimension for roof glazing: 12500 x 2000 mm
Net Weight
: 200 kg
Selected additional services
:
Vacuum suction system for wall and roof panels up to 18 m.
max. pane dimension for wall glazing: 18500 x 3000 mm
max. pane dimension for roof glazing: 18500 x 2000 mm
Net Weight
: 280 kg
Selected additional services
:
Vacuum suction system for wall and roof panels up to 24 m.
max. pane dimension for wall glazing: 24551 x 3000 mm
max. pane dimension for roof glazing: 24551 x 2000 mm
Net Weight
: 280 kg
Selected additional services
:
Vacuum suction system for wall and roof panels up to 8 m.
max. pane dimension for wall glazing: 8500 x 2000 mm
max. pane dimension for roof glazing: 8500 x 2000 mm
Net Weight
: 260 kg
Selected additional services
:
600 kg capacity, 8 plates, 180 kg weight, 3 axis manipulator with cable remote control for MRK 126 - 158
Net Weight
: 180 kg
Selected additional services
:
Vacuum suction system for assembling glass fins up to 1000 kg and 12 m width.
Net Weight
: 350 kg
Selected additional services
:
for safe trannsport and setting of panes up to 2,800mm suction length
robust and solid construction
max. pane dimension for wall glazing: 4400 x 2800 mm
max. pane dimension for roof glazing: 3400 x 1800 mm
Net Weight
: 70 kg
Selected additional services
:
The perfect solution for lifting and installing window elements weighing up to 600 kg.
Minimum pane size: 810 x 700 mm
max. pane dimension for wall glazing: 4400 x 2800 mm
max. pane dimension for roof glazing: 3400 x 1800 mm
Net Weight
: 70 kg
Selected additional services
:
with cable remote control
for attach on assembly crane MRK 195, and loader crane
Net Weight
: 65 kg
Selected additional services
:
suitable for long glass fins
Minimum pane size: 2.000 x 300 mm
max. pane dimension for wall glazing: 4000 x 2300 mm
max. pane dimension for roof glazing: 3000 x 1300 mm
Net Weight
: 82 kg
Selected additional services
:
suitable for extra-long glass fins
max. pane dimension for wall glazing: 6000 x 2300 mm
max. pane dimension for roof glazing: 5000 x 1300 mm
Net Weight
: 101 kg
Selected additional services
:
suitable for extra-long glass fins
max. pane dimension for wall glazing: 10000 x 2400 mm
max. pane dimension for roof glazing: 9000 x 1400 mm
Net Weight
: 116 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 330
Pane dimensions (LxW) LA9 in mm 12,123 x 330
Pane dimensions (LxW) LA12 in mm 15,123 x 330
Pane dimensions (LxW) LA14 in mm 17,123 x 330
max. pane dimension for wall glazing: 17123 x 330 mm
max. pane dimension for roof glazing: 17123 x 330 mm
Net Weight
: 450 kg
Selected additional services
:
Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms
Min. Suction (L x W) in mm (base frame) variable up to 1,200 x 1,000
max. pane dimension for wall glazing: 4200 x 2600 mm
max. pane dimension for roof glazing: 4200 x 2600 mm
Net Weight
: 276 kg
Selected additional services
:
Suitable for long, narrow panes (glass fins/glass beams)
Minimum pane size: 2,000 x 400 mm
max. pane dimension for wall glazing: 10000 x 2400 mm
max. pane dimension for roof glazing: 9000 x 1400 mm
Net Weight
: 116 kg
Selected additional services
:
Net Weight
: 220 kg
Selected additional services
:
Suitable for long, narrow panes (glass fins/glass beams)
Minimum pane size: 1350 x 350 mm
max. pane dimension for wall glazing: 5300 x 3200 mm
max. pane dimension for roof glazing: 3350 x 2100 mm
Net Weight
: 95 kg
Selected additional services
:
Suitable for long, narrow panes (glass fins/glass beams)
Minimum pane size: 2000 x 1110 mm
max. pane dimension for wall glazing: 7900 x 3200 mm
max. pane dimension for roof glazing: 7000 x 2600 mm
Net Weight
: 105 kg
Selected additional services
:
For mounting longitudinally curved panes
Minimum pane dimensions: 4000 x 1500 mm
max. pane dimension for wall glazing: 7500 x 3000 mm
max. pane dimension for roof glazing: 6500 x 2000 mm
Net Weight
: 410 kg
Selected additional services
:
up to 600 kg panes
Selected additional services
:
Easy operation by one employee
Ergonomic and energy-saving work
Faster laying of large-format flags
Net Weight
: 1060 kg
Lift Height
: 3.6 m
Selected additional services
:
compact mobile assembly aid transports and places
Precise fitting with fine stroke
pane dimensions in square min.: 730 x 730 mm
Net Weight
: 1300 kg
Lift Height
: 3.6 m
Selected additional services
:
Easy operation by one employee
Ergonomic and energy-saving work
With unique vertical lift for inserting the fire protection closure onto the pins
Net Weight
: 1060 kg
Lift Height
: 3.6 m
Selected additional services
:
made of aluminium
very robust design
red-line indicator
suction area Ø 225 mm
incl. practical plastic protective case
Net Weight
: 3 kg
Selected additional services
:
Vacuum suction system for screen printing and stone slabs up to 540 kg.
Net Weight
: 220 kg
Selected additional services
:
An alternative to assembly crane 158.0 but with a 2 tonnes higher capacity. Loads up to 800 kg can be positioned under eaves and even behind scaffolding with the heavy-load tips up to 4 m.
Net Weight
: 4835 kg
Lift Height
: 15.8 m
Selected additional services
:
Currently the BIGGEST SYSTEM on the market! Lifts, rotates and pivots panes up to 24 metres in length, 3.2 m wide and weighing up to 5,000 kg with the highest level of safety and precision!
Overall depth in mm 550
Suction (LxW) in mm (Base frame) 6,123 x 1,900
Suction (L x W) in mm with extension arms 12,073 x 2,200 short arms / 18,073 x 2,200 long arms
max. pane dimension for wall glazing: 20073 x 4200 mm
max. pane dimension for roof glazing: 19073 x 3200 mm
Net Weight
: 2500 kg
Selected additional services
:
For curved panes, concave and convex, from 450 mm inner und outer radius, 134 plates, hydraulically swivelable, with remote control, 2800 kg weight, max. suction length: 6000 mm + 2x 3000 mm extension arms, incl. roll truck
max. pane dimension for wall glazing: 19073 x 2200 mm
max. pane dimension for roof glazing: 19073 x 2200 mm
Net Weight
: 2800 kg
Selected additional services
:
VSG Konter up to 5,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 6800 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
Pane dimensions (LxW) LA9 in mm 12,270 x 550
Pane dimensions (LxW) LA12 in mm 15,270 x 550
Pane dimensions (LxW) LA14 in mm 19,270 x 550
max. pane dimension for wall glazing: 19270 x 550 mm
max. pane dimension for roof glazing: 19270 x 550 mm
Net Weight
: 1300 kg
Selected additional services
:
dispersible glass wagon made out of steel pipe, yellow chromated, all-terrain, variable costumizable on glass pane
Min. pane dimensions in mm L 500 x H 500 Max. pane dimensions in mm L 2,500 x H 2,500
Net Weight
: 32 kg
Selected additional services
:
Due to a safe 4-point-base, the product is guaranteed a very stable position and shock absorption during transportation on uneven construction sites.
Net Weight
: 20 kg
Selected additional services
:
Double safety with full-stop wheels: Brakes in direction and position with only one lever pressure!
Using a mechanical hand crank, the glass pane can be turned horizontally up to 45°.
Min. pane dimensions in mm L 1,500 x H 1,000 Max. pane dimensions in mm L 2,500 x H 3,200
Net Weight
: 110 kg
Selected additional services
:
500 kg capacity, 15 m chain, 15 m cable remote control, chain storer, 55 kg, 380 V drive, 2 speed
Net Weight
: 55 kg
Lift Height
: 15 m
Selected additional services
:
500 kg capacity, 25 m chain, 25 m cable remote control, chain storer, 60 kg, 380 V drive, 2 speed
Net Weight
: 60 kg
Lift Height
: 25 m
Selected additional services
:
500 kg capacity, 30 m chain, 30 m cable remote control, chain storer, 70 kg, 380 V drive, 2 speed
Net Weight
: 70 kg
Lift Height
: 30 m
Selected additional services
:
500 kg capacity, 6 m chain, 6 m cable remote cotrol, chain storer, 30 kg, 380 V drive, 2 speed
Net Weight
: 30 kg
Lift Height
: 6 m
Selected additional services
:
For curved panes, convex and concave, from 450 mm inner and outer radius, 24 plates, manually rotatable, hydraulically tippable, with remote control, 140 kg weight, suction length: 1125 mm, incl. roll truck
max. pane dimension for wall glazing: 4500 x 2300 mm
max. pane dimension for roof glazing: 3500 x 1300 mm
Net Weight
: 250 kg
Selected additional services
:
very variable system with extension arms
Suction (LxW) in mm 1,188 x 829
Suction (LxW) in mm with extension arms 2,330 x 1,490 or (optional 4,050 x 700)
max. pane dimension for wall glazing: 4118 x 3829 mm
max. pane dimension for roof glazing: 3118 x 2829 mm
Net Weight
: 91 kg
Selected additional services
:
7-axle-manipulator with remote control for lifting with an indoor or outdoor telescopic forklift.
Net Weight
: 1000 kg
Selected additional services
:
Double safety with full-stop wheels: Brakes in direction and position with only one lever pressure!
Using a mechanical hand crank, the glass pane can be turned horizontally up to 45°.
Min. pane dimensions in mm L 1,500 x H 1,000 Max. pane dimensions in mm L 2,500 x H 3,200 In dual mode max. in mm L 6,000 x H 3,200
Selected additional services
:
VSG Konter up to 500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane
Net Weight
: 1600 kg
Selected additional services
:
long design
for assembly from a high to low position
suitable for indoor and, with laid out floor plates, also for outdoor areas
Net Weight
: 674 kg
Lift Height
: 2.9 m
Selected additional services
:
From planning to assembly - Heavydrive is your partner when it comes to Helm running rails!
Selected additional services
:
All-round suction system, variable thanks to attachable arms
Minimum pane size: 810 x 700 mm
max. pane dimension for wall glazing: 4400 x 2800 mm
max. pane dimension for roof glazing: 3400 x 1800 mm
Selected additional services
:
Load capacity up to 8.8 m height = 500 kg
with battery-operated mast lift
Net Weight
: 237 kg
Lift Height
: 8.8 m
Selected additional services
:
This diesel-driven assembly crane has a capacity of 4.9 tonnes and is movable under a load of 2 tonnes.
Net Weight
: 9700 kg
Lift Height
: 16.35 m
Selected additional services
:
compact mobile assembly aid transports and places
Precise fitting with fine stroke
pane dimensions min.: 660 x 540 mm
Net Weight
: 932 kg
Lift Height
: 2.56 m
Selected additional services
:
Perfectly suited for huge panes up to 9 m long, up to 3.8 m wide and weighing up to 4,500 kg. Choose the highest safety standards with a 4-circuit system!
Overall depth in mm 550
Suction (LxW) in mm (Base frame) 4,300 x 1,810
Suction (LxW) in mm with extension arms 7,000 x 1,810
max. pane dimension for wall glazing: 9000 x 3810 mm
max. pane dimension for roof glazing: 8000 x 2810 mm
Net Weight
: 1350 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
Pane dimensions (LxW) LA9 in mm 12,270 x 550
Pane dimensions (LxW) LA12 in mm 15,270 x 550
Pane dimensions (LxW) LA14 in mm 19,270 x 550
max. pane dimension for wall glazing: 19270 x 550 mm
max. pane dimension for roof glazing: 19270 x 550 mm
Net Weight
: 1300 kg
Selected additional services
:
VSG Konter up to 4,500 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 6800 kg
Selected additional services
:
Light system for window assembly up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high. The short hanger assists assembly in window openings.
Suction (L x W) in mm (base frame) 900 x 680
Suction (L x B) in mm with extension arms 2,100 x 680
max. pane dimension for wall glazing: 3900 x 2500 mm
max. pane dimension for roof glazing: 1900 x 1680 mm
Net Weight
: 45 kg
Selected additional services
:
Perfectly suited to glazing behind scaffolding
max. pane dimension for wall glazing: 4000 x 2300 mm
max. pane dimension for roof glazing: 3000 x 1300 mm
Net Weight
: 40 kg
Selected additional services
:
Perfectly suited to glazing behind scaffolding
max. pane dimension for wall glazing: 5000 x 2300 mm
max. pane dimension for roof glazing: 4000 x 1300 mm
Net Weight
: 55 kg
Selected additional services
:
Safe transport of panes. Thanks to a super flat construction of 160 mm this is the best assistant for assembly behind scaffolding!
Suction (L x W) in mm 1,300 x 780 mm
max. pane dimension for wall glazing: 3300 x 2780 mm
max. pane dimension for roof glazing: 2300 x 1780 mm
Net Weight
: 116 kg
Selected additional services
:
with cable remote control
for attach on assembly cranes MRK 55.0 - 158.0
Selected additional services
:
Perfectly suited to glazing behind scaffolding
max. pane dimension for wall glazing: 8000 x 2300 mm
max. pane dimension for roof glazing: 7000 x 1300 mm
Net Weight
: 80 kg
Selected additional services
:
VSG 450 KRQ Vacuum Suction System suitable for glass panes curved along the side up to H 2500 x B 6000 mm.
max. pane dimension for wall glazing: 7500 x 3000 mm
max. pane dimension for roof glazing: 6500 x 2000 mm
Net Weight
: 380 kg
Selected additional services
:
Light system for stone slab assembly up to 450 kg. Best suited to small sizes up to
Net Weight
: 45 kg
Selected additional services
:
Light system for assembly of coated panes up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high.
max. pane dimension for wall glazing: 3900 x 2500 mm
max. pane dimension for roof glazing: 1900 x 1680 mm
Net Weight
: 45 kg
Selected additional services
:
Light system for window assembly up to 450 kg. Best suited to small sizes up to 1m wide and 1,20m high.
max. pane dimension for wall glazing: 3900 x 2500 mm
max. pane dimension for roof glazing: 1900 x 1680 mm
Net Weight
: 45 kg
Selected additional services
:
Up to 3.5 m lifting height
450 kg rollable under load
Lift by manual hand crank
Lift Height
: 3.5 m
Selected additional services
:
for safe trannsport and setting of panes up to 2,800mm suction length
robust and solid construction
max. pane dimension for wall glazing: 4400 x 2800 mm
max. pane dimension for roof glazing: 3400 x 1800 mm
Net Weight
: 140 kg
Selected additional services
:
with cable remote control
for attach on assembly cranes MRK 55.0 - 158.0
Net Weight
: 180 kg
Selected additional services
:
Perfectly suited to glazing behind scaffolding
max. pane dimension for wall glazing: 5000 x 2300 mm
max. pane dimension for roof glazing: 4000 x 1300 mm
Net Weight
: 55 kg
Selected additional services
:
with cable remote control
for mounting to our assembly cranes MRK 55.0 - 158.0
Net Weight
: 150 kg
Selected additional services
:
Vacuum suction system for screen-printed panels and stone slabs .Slabs are held in an almost vertical position. The suction length is 2800 mm
Net Weight
: 220 kg
Selected additional services
:
For mark-free installation of coated panes
Minimum pane size: 1363 x 1290 mm
max. pane dimension for wall glazing: 4998 x 2890 mm
max. pane dimension for roof glazing: 3998 x 2290 mm
Net Weight
: 206 kg
Selected additional services
:
from 450 mm on up can be suctioned at the inner or outer radius
Even wavy panes are not a problem
Min. Suction (L x W) in mm (base frame) 1,290 x 254
Max. Suction (L x W) in mm (base frame) 1,770 x 254
max. pane dimension for wall glazing: 2290 x 1890 mm
max. pane dimension for roof glazing: 2290 x 1890 mm
Net Weight
: 38 kg
Selected additional services
:
Vacuum suction system for heavy panes and façade elements up to 4000 kg
Minimum pane size: 6123 x 1900 mm
max. pane dimension for wall glazing: 14100 x 3600 mm
max. pane dimension for roof glazing: 13100 x 2600 mm
Net Weight
: 1800 kg
Selected additional services
:
For curved panes, concave and convex, from 450 mm inner und outer radius, 108 plates, hydraulically swivelable, with remote control, 2500 kg weight, max. suction length: 4000 mm + 2x 400 mm extension arms, incl. roll truc
max. pane dimension for wall glazing: 9500 x 3300 mm
max. pane dimension for roof glazing: 8500 x 2330 mm
Net Weight
: 2500 kg
Selected additional services
:
VSG Konter up to 4,000 kg capacity. Secure mounting of the pane under protrusions up to 3.0 m. The system can be attached to any construction crane, tower crane, loading crane or mobile crane.
Net Weight
: 6300 kg
Selected additional services
:
Ideal for setting very long glass fins
Pane dimensions (LxW) L4/6 in mm 7,123 / 9,123 x 550
Pane dimensions (LxW) LA9 in mm 12,270 x 550
Pane dimensions (LxW) LA12 in mm 15,270 x 550
Pane dimensions (LxW) LA14 in mm 19,270 x 550
max. pane dimension for wall glazing: 19270 x 550 mm
max. pane dimension for roof glazing: 19270 x 550 mm
Net Weight
: 1300 kg
Selected additional services
:
Twin set glass wagon for secure transport.
A bearing load of up to 400 kg and a working width of 155 mm make it possible to transport several light window parts in combination.
Net Weight
: 18.2 kg
Selected additional services
:
Twin set glass wagon for secure transport
to transport several light window parts in combination
optional with an additional guid rod for protective handle and safe placement
Net Weight
: 12 kg
Selected additional services
:
Up to 4 m lifting height
400 kg rollable under load
Lift by manual hand crank
Lift Height
: 4 m
Selected additional services
:
Lifting beam for transporting long loads by crane, grid adjustable from 300 to 1200 mm
Net Weight
: 15 kg
Selected additional services
:
Lifting beam for transporting long loads by crane, grid adjustable from 300 to 800 mm
Net Weight
: 15 kg
Selected additional services
:
This assembly crane has a capacity of 3.83 tonnes, is movable under a load of 500 kg and fits optimally into industrial lifts.
Net Weight
: 6500 kg
Lift Height
: 16.8 m
Selected additional services
:
narrow design with short chassis
for many different applications
suitable for indoor and, with laid out floor plates, also for outdoor areas
Net Weight
: 168 kg
Lift Height
: 2.9 m
Selected additional services
:
compact mobile assembly aid transports and places
Precise fitting with fine stroke
Net Weight
: 732 kg
Lift Height
: 3 m
Selected additional services
:
Assembly lift up to 2.85 m lifting height and 400 kg load capacity.
Only 1.76 m high!
Lift by manual hand crank
Net Weight
: 289 kg
Lift Height
: 2.85 m
Selected additional services
:
Page 1 of 4
All categories and products
Assembly Cranes
Vacuum Suction Systems
Counterweight units
Overhead Assembly
Glass assembly devices
Glass Transport Wagons
Auxillary equipment
Services
Options
