Data sheet


VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity





Services included

  • Advice on rental, purchase and project planning
  • Handling service
  • Payment and financing options
  • Fast and customised delivery options
  • Long-term rental models
  • Equipment replacement & spare parts service/li>
  • Digital services
  • Tested quality/li>

Optional additional services

  • Express delivery
  • Maintenance Plus
  • Instruction/training
  • Planning and advice service
  • Device operator
  • Handling Service
Brief description

  • from 450 mm on up can be suctioned at the inner or outer radius
  • Even wavy panes are not a problem
  • Min. Suction (L x W) in mm (base frame) 1,290 x 254
  • Max. Suction (L x W) in mm (base frame) 1,770 x 254

Long description

Suction systems for panes weighing up to 405 kg for external and internal radii from 450 mm (concave or convex curved and wavy panes). These systems are adaptable to any pane size. Adjustable to fit on the pane by slidable and rotatable suction cups and by using different attachment arms








Data sheet (VSG 405 PLR)


Features

Capacity: 405 kg
Net Weight: 38 kg
Overall depth: 233 mm
Pane vertical dimensions max.: 2290 x 1890 mm
Pane horizontal dimensions max.: 2290 x 1890 mm
Suction (L x W) (base frame): 1290 x 254 mm
Suction Cups : 6 x T13
Tilting : 90°
Rotation : 180°
Lock : 90°
Safety System : 2 circuit vacuum system
Battery : 12 V, 3-4 days continuous use, without recharging (recharging via 220 V plug)

Further product images

VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity | VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity
VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity | VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity
VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity | VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity
VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity | VSG 405 PLR - Vacuum Suction Systems for Curved Panes up to 405 kg capacity
