Data sheet


MRK 144.0 assembly crane with a capacity of 2.9 tonnes





Services included

  • Advice on rental, purchase and project planning
  • Handling service
  • Payment and financing options
  • Fast and customised delivery options
  • Long-term rental models
  • Equipment replacement & spare parts service/li>
  • Digital services
  • Tested quality/li>

Optional additional services

  • Express delivery
  • Maintenance Plus
  • Instruction/training
  • Planning and advice service
  • Device operator
  • Handling Service
Brief description

This assembly crane has a capacity of 2.9 tonnes and its 1.6 m heavy-load tip is extensible to a length of 3 m.


Long description

By means of a patented HEAVYDRIVE crane extension tip, this mini caterpillar crane can be lengthened up to 3 m. With a capacity of 2.93 tonnes and a basic hook height of 14.4 m, this is a real all-rounder, which can be electrically powered or diesel powered, making it suitable for both indoor and outdoor use. With its caterpillar tracks, it can drive on any ground and thanks to its non-marking (non-colouring) tracks, it can also be driven on building floors. Through various special HEAVYDRIVE assembly tips, you can even reach under eaves, behind scaffolding and many other places. In combination with our vacuum suction systems, you can bring almost every pane and panel to its destination. Additionally, this crane can be manoeuvred by wireless remote control.








Data sheet (MRK 144.0)


Features

Lift Height: 14.9 m
Load capacity (goods to be lifted): 3,9 t x 2,5 m
Net Weight: 4000 kg
Max. Hook Height Incl. tip S1 : 19,8 m with 4,1 m tip
Safety System : Load torque limiter Boom angle and load gauge Hydraulic pressure safety valve Hook securer Self-locking engine brake Winch cut
Max. Working Radius : 14,4 m
Cable : IWCR 8 mm x 77 m

Telescopic System
Telescoping Speed : 10,98 m/ 23 s
Turning Angle : 360° continous
Turning Speed : 2,5 RPM
Cable Speed : 17 m/ min.
Supporting Feet : Fully hydraulic

Carriage
Drive : Hydrostatic, continuously variable forward and reverse
Speed : 0- 3 km/ h
Gradability : 23°
Running Gear Length : 1750 mm
Ground Pressure : 0,34 kg/ cm²
Chain Width : 300 mm

Motor
Type : Mitsubishi Diesel 24,5 PS
Performance : 14 KW / 2400 U/ min
Fuel : Petrol and electric
Tank Capacity : 40 l

Further product images

MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
MRK 144.0 assembly crane with a capacity of 2.9 tonnes | MRK 144.0 assembly crane with a capacity of 2.9 tonnes
